PXI 7-Chan 20A Fault Switch, One Fault Bus - 40-194-001

The 40-194 is a 7 Channel Fault Insertion switch designed for the simulation of fault conditions in automotive systems. As well as high current handling of 20A, very low currents can also be switched. It is designed to be able to insert different fault conditions between the test fixture and the equipment under test.

  • 7 Fault Insertion Channels
  • Simulation of Various Types of Electrical Fault, Enabling Rigorous Fault Testing
  • Choice of 1 or 2 Fault Buses
  • Hot or Cold Switch Currents From Less Than 1mA to 20A
  • Switch up to 16 Volts DC
  • VISA, IVI and Kernel Drivers Supplied for Windows
  • Supported by PXI or LXI Chassis
Platform PXI
Switch Type EMR
Fault Buses 1
Max I (A) 20
Max V DC 16
Channels 7
Brand Pickering Interfaces
