PXI 16xDPST 2A General Purpose Relay Module - 40-132-102

The 40-132-102 16xDPST 2 Amp Relay Module is part of our range of PXI medium power switching solutions and is suitable for general purpose switching applications.

Features
  • Low Cost Relay Card For Medium Power Switching Applications
  • Up to 32 Electromechanical Relays Per Module
  • Choice of SPST, SPDT or DPST Contact Configurations
  • Maximum Current 2A Hot or Cold Switching
  • Switch up to 300VDC/250VAC and up to 60W Max Power
  • Operating Speed <3ms
  • VISA/IVI & Kernel Drivers Supplied for Windows
  • Supported by PXI or LXI Chassis
Platform PXI
Relay Contacts DPST
Switch Type EMR
Poles 2
Max I (A) 2
Max V DC 300
Relays 16
Brand Pickering Interfaces
