8x4 2xGMCT,2-Pole,PowerMatrix,40-550-902

The World's highest density 2-pole single slot 3U PXI Matrix Module, the 40-581 has 264 crosspoints configured as a 2-pole 33x8 matrix. The use of high density electromechanical relays means that the 40-581 is a low cost high density matrix solution with current handling up to 1 Amp. The 40-581 module is suitable for matrix applications where two signals are required to be switched simultaneously, for example send and return signals in a telecoms system. It is also suitable for applications where reed relay based matrices do not have sufficient power handling capability.

Features
  • 5A current rating with 150W/1250VA maximum power
  • Hot switch to 125VDC/250VAC, cold switch to 400VDC/250VAC
  • VISA, IVI and Kernel Drivers Supplied for Windows
  • Supported by PXI or LXI chassis
Platform PXI
Switch Type EMR
X Size 8
Y Size 4
Banks 1
Poles 2
Max I (A) 5
Max V DC 400
Brand Pickering Interfaces
